Kenwood NX 3220 3320 3420 NX3220 NX3320 Handheld Radio
The Kenwood NX 3220 / 3320 / 3420 handheld radio, renowned for its versatility, actively supports both NXDN and DMR digital protocols, along with the capability for mixed digital and FM analog operation. This feature-rich device is tailor-made for a broad spectrum of enterprise- and operation-critical applications. Despite its compact form, it prioritizes durability and is equipped with practical features such as Bluetooth® for hands-free operation and a built-in GPS.
Model: NX-3220 / NX-3320 / NX-3420
Brand: kenwood
Frequency Band: UHF, VHF, 800/900MHz
Channel Capacity: 260
Dust and Water Intrusion: IP54/55/67
Battery: 1480/2000/2860mAh(Li-Ion)
Zone Capacity: 128
| Model | NX-3220 | NX-3320 |
| Frequency Band | 136-174 MHz | 400-520MHz |
| Channel Capacity | 260 (64 for no LCD models) | |
| Number of Zones | 128 (4 for no LCD models) | |
| Max. Channels Per Zone | Up to 1000 channels with option | |
| Power Output | 1W / 4W / 5W | |
| Channel Spacing |
Analog: 12.5 / 20 / 25 / 30kHz |
|
| Operating Temperature | -30°~ +60 °C | |
| Frequency Stability | ± 0.5 ppm | |
| Power Supply | 7.5 V DC ±20 % | |
| Contact us for latest prices | ||
Feature
Available in three distinct models, the Kenwood handheld radio caters to diverse preferences. The Full Keypad model boasts an LCD for comprehensive functionality, the Standard Keypad model features an LCD accompanied by a large 4-way D-pad, and the Basic Model, without an LCD or keypad, offers simplicity. Furthermore, for enhanced expansion capability, a software license certification system facilitates extensive customization, ensuring that the Kenwood handheld radio meets the specific needs of various users.
- Multi-protocol digital radio: Designed to operate under an NXDN or DMR digital, and FM analog protocols
- NXDN Conventional and Type-C & Gen2 Trunking
- DMR Tier II & Site Roaming
- Mixed Digital & FM Analog Operation allows gradual migration at your own pace
- 4-Line Basic Frame (2-Line Main/SubLCD, icon & key guide) / 14 Characters
- 5-Line Text Message Frame (3 Lines of Text, icon & key guide)
- 7-color Light Bar Indicator on the top panel
- 4-way Directional-pad (D-pad) for intuitive control and operation
- Built-in GPS Receiver/Antenna for effective fleet management
- Built-in Bluetooth for hands-free operation – Applicable Bluetooth profiles: HSP (Headset Profile provided) and SPP (Serial Port Profile available as an option)
- Renowned KENWOOD Audio Quality can be achieved with Active Noise Reduction (ANR) that utilizes built-in DSP
- Software DES and AES Encryptions for NXDN Conventional/Trunking and DMR Conventional protocols
- Built-in Motion Sensor (Man-down, Stationary and Motion Detection)
- IP54/55/67 and MIL-STD-810 C/D/E/F/G
